ASTM JIS Window Tint Checker Reader Meter Light Transmittance Tester
Product Description
Applicable to measure the transmittance or haze of all kinds of transparent, translucent samples with parallel plane (such as automobile manufacturing, aerospace, glass products, plastic sheet, sheet, etc.). Also can be used to determine the turbidity or clarity of liquid sample (water, drinks and so on).
* Digital display, wide measurement range, high resolution.
* One key calibration, easy to use.
* Solid structure, small volume, light weight, exquisite, easy to carry.
* Use “USB data output” and “RS-232 data output” to connect with PC.
Display | 10mm LCD |
Measurement Range | 0 to 100% Light Transmission |
Resolution | 0.1 |
Accuracy | ± 2 % |
Sample Thickness | Less Than 18mm / 0.7inch |
Light Source | LED |
Measuring Mode | Single / Continuous |
Operating conditions | Temperature: 0 ~ 50 ℃ Humidity: < 90 % |
Power Supply | 4 x 1.5 V AAA Size (UM-4) Battery |
Dimensions | Unit: 126 x 65 x 27 mm (5.0 x 2.6 x 1.1 inch) |
Sensor: 125 x 38 x 38 mm | |
Weight | 100 g (Not Including Batteries) |
