8mm caliber colorimeter painting metal color difference meter
Product Advantages:
- 1. Built-in white plate parameters. No need to calibrate each time which can perform measurement quickly.
- 2. Double Locating: Illuminating locating and precise cross locating.
- 3. Switchable Double Measurement End Face: Large stable end face and small concave-convex end face.
- 4. New 45°/0° Optical Path Design: Significantly improve the measurement stability and precision.
- 5. 8mm Measuring Aperture.
- 6. Equipped with rechargeable high-capacity Li-ion battery. No need to purchase battery repeatedly.
- 7. Configure CQCS3 software. Connect PC computer to realize more functions.
- 8. Having got SCM Metrological Certification, CE Certification, and ISO9001 Quality Management System Certification.
- 9. Hand-head structure: small and convenient; make the measurement easier.
- 10. Exquisite appearance: adopts traditional and fashionable aesthetic designs.
Illuminating/Viewing Geometry
|
45°/0°
|
Measuring Aperture
|
Φ8mm
|
Measurement End-face
|
Large stable end face
|
Detector
|
Silicon photoelectric diode
|
Locating
|
Illuminating Locating/Cross Locating
|
Color Space
|
CIEL*a*b*C*h* CIEL*a*b*
CIEXYZ
|
Color Difference Formula
|
△E*ab △L*a*b* △E*C*h*
|
Light Source
|
D65
|
Light Source Device
|
LED blue light excitation
|
Errors Between Each Equipment
|
≤0.80ΔE*ab
|
Storage
|
100pcs standards 20000pcs samples
|
Repeatability
|
Standard deviation within ΔE*ab 0.08
Average of 30 measurements of standard white plate
|
Weight
|
500g
|
Dimension
|
205×67×80 mm
|
Power source
|
Rechargeable lithium-ion battery 3.7V@3200mAh
|
Lamp Life
|
5 years, more than 1.6 million measurements
|
Charging Time
|
The first charging time is 8 hours–100% electricity
|
PC Software
|
CQCS3 Software
|
Printer (optional)
|
Miniature thermal printer
|
