Digital Inclinometer Clinometer Slope Tilt Sensor 0.001
Part NO: INCL-2001
INCL-2001 is single axis digital inclinometer With Repeatability:0.003°. It is high accurate instruments designed to measure the angle of inclination of something, especially from the horizontal. angles of slope (or tilt), elevation or depression of an object with respect to gravity. It is also known as a tilt meter, tilt indicator, slope alert, slope gauge, gradient meter, gradiometer, level gauge, level meter. INCL-810 is another unique design of ROK International With large display and color figure. Inspector can read the data directly. Adopting the micro-mechanical control principle, dual-core measurement unit, It can use the Y-axis to compensate X-axis during the measurement process; slope alert; gradiometer slope alert slope gauge, gradient meter,
Specification: -Best accuracy:<0.003°
Angle Measuring range | INCL2001:±15 ° ; | INCL2001:±30 ° ; | ° |
MM measuring range | 267 | 577 | mm |
Measuring axis | Single axis | Single axis | |
The highest measuring accuracy | <0.005 (Full measuring range) | <0.01 (Full measuring range) | ° |
Angle Measuring resolution | 0.001 | 0.001 | ° |
MM measuring accuracy | 0.1 | 0.2 | mm |
Three measurement mode selectable | radian, angle, mm measuring can be selected | ||
MM measuring res | 0.02 | mm | |
LCD | 64 true colors night vision display screen | ||
LCD visible area size | L57.6*W43.2 | mm | |
Working temperature | -10°~ +70℃ | °/℃ | |
Working humidity | 85 | %RH | |
Power supply | 3.7VCharging Lithium battery | V | |
Ideal charging time | 3~4 | h | |
Battery sustainable charging times | 11 | h | |
Equipped with PC software | VC software | ||
Data output signal | USB1.1 | ||
Connect plug in | Standard 5Pin USB connector | ||
Shock resistance | 10g@11ms, 3Times/Axis(half sinusoid) | g | |
Shock impact | 10grms, 10~100Hz | g | |
Weight | 300 | g | |
Waterproof grade | IP54 | ||
Material | Metal | ||
Size | L107*W75*H27.1mm | mm |
