Ultra thin rugged tablet IP67 for industrial user
IPS / Display: 8-inch 1920*1200 resolution, IPS
Processor: MT8788(8-core, 2.0ghz)
capacity: 4G+128G,8G+256G
Camera: front 800W, back 1300W, supporting flash
Battery: 10000MAH (removable)
Built-in encryption chip
Speaker :(2*8 ohm 1W)
Support poGO-PIN, external extension of the UART interface peripherals
Support fingerprint identification
Support USB Type-C (1*USB2.0 OTG)
Support USB TYPE – A (2 * USB2.0)
Support gravity acceleration, gyroscope, compass
Support WIFI, BT, 4G
Support the recording
Support the recording
Accessories: hand strap, braces, independent charging base
Features:
1. Dustproof and waterproof grade is IP67
2. the naked machine can resist dropping 1.2m
3. the standard for the electrostatic air 16kv, the contact of 8kv
4. 5 PIN pogo-pin port, support charging, keyboard (USB port)
5. working temperature: -10 to 50 degrees, storage temperature -20 to 60 degrees
6. built-in encryption IC
7.Ultra-thin design 16.5mm thickness
8. can expand 12PIN external function module interface
9. removable back support frame
Specification:
Type | Details | Descriptions | ||||
CPU | Type | MT8788( 8-core processor) | ||||
Speed | 2.0GHz | |||||
GPU | Type | ARM G76 | ||||
RAM | Capacity | 4GB or 8GB LPDDR4X | ||||
ROM | Capacity | UFS(up to 256GB) | ||||
TF card | Capacity | 32GB ~ 128GB(up to 128GB) | ||||
Camera | Front | 8MP | ||||
Rear | 13MP(AF) | |||||
2* Microphone | ||||||
Speaker | Built-in | 2*8Ω/1W | ||||
Flashlight | Built-in | YES | ||||
Powerlight | Built-in | YES Red and green | ||||
G_sensor | Built-in | YES | ||||
Light sensor | Built-in | YES | ||||
Distance sensor | Built-in | YES | ||||
Compass | Built-in | YES | ||||
Gyroscope | Built-in | YES | ||||
Button battery | Built-in | YES | ||||
IC Encryption IC | Built-in | YES | ||||
GPS | Built-in | YES(BeiDou,Glonass,GPS) | ||||
WIFI | Built-in | WIFI 802.11 ac/a/b/g/n | ||||
Bluetooth | Built-in | BT 4.0 | ||||
NFC | Built-in | YES (optional) | ||||
Fingerprint | Built-in | YES (optional) | ||||
Barcode scanner | Built-in | YES (optional) | ||||
GPS High precision GPS module | optional Configuration | YES(Optional, requires additional newly opened accessories) | ||||
RFID module | optional Configuration | YES(Optional, requires additional newly opened accessories) | ||||
4G | Built-in | LTE FDD:B1/B3/B5/B8; LTE TDD:B34/B38/B39/B40/B41 WCDMA:B1,B5 ,B8 TD-SCDMA:B34,B39 GSM:B3,B8 |
||||
(Interface Configuration) | ||||||
Type | Details | Descriptions | ||||
TF Memory card socket | External memory | standard TF card(up to 128GB) | ||||
SIMSim card interface | Built-in | Nano SIM card | ||||
USB TYPE-C interface | Data transfer supportive | TYPE-C(USB3.0 OTG +Digital microphone) | ||||
USB TYPE-A interface | Data transfer supportive | 2*TYPE-A(USB 2.0) | ||||
HDMI interface | Video output | Micro HDMI | ||||
Key interface | Pot button | ON/OFF,VOL+,VOL-,F1 | ||||
Docking Station interface | 内置 Built-in | 5 PIN(charge+keyboard) | ||||
Software Configuration | ||||||
Type | Details | Descriptions | ||||
Operating System | version | Andriod11 | ||||
Language | Multi-language supportive | |||||
Standard Configuration | ||||||
Type | Details | Descriptions | ||||
Adapter | Standard Configuration | DC charger (19V/3A) | ||||
Docking station | optional Configuration | external function for charger | ||||
Shoulder strap | optional Configuration | Custom shoulder strap | ||||
Battery charging base | optional Configuration | can charge 4 batteries at the same time | ||||
Adjustable angle carriage | optional Configuration | from 90 degrees to 150 degrees |
